What are the sizes corresponding to different diameters of vortex flowmeters?

Vortex flowmeters of different diameters correspond to different sizes, and products produced by different manufacturers may have differences in specific dimensions. Taking the common DN25 caliber as an example, its length is generally around 150mm and the outer diameter is about 32mm. The DN50 caliber vortex flowmeter has a length of about 200mm and an outer diameter of about 57mm. For DN80 caliber, the length is usually around 250mm and the outer diameter is about 89mm. For DN100 caliber, the length is about 300mm and the outer diameter is about 108mm. When the caliber increases to DN150, the length is about 400mm and the outer diameter is about 159mm. The length of a DN200 caliber vortex flowmeter is generally around 500mm and the outer diameter is about 219mm. These dimensional data are only approximate ranges. In practical applications, when selecting a vortex flowmeter, accurate dimensional information should be obtained based on the product manual and specification parameter table provided by the specific manufacturer to ensure correct installation and use.

2. Flow Range of Steam Vortex Flow Meter

Code: Tongrentqi Radial Flow Range ㎡/h OW-LU-25 DN25 1~10 (liquid) 25~60 (gas) Steam Flow Please refer to the instructions of Yiyanling. For DN300 and above, it is recommended to use the plug-in vortex flow meter OW-LU-32 DN32 1.5~18 (liquid) 15~150 (gas) OW-LU-40 DN40 2.2~27 (liquid) 22.6~150 (gas) OW-LU-50 DN50 4~55 (liquid) 35~350 (gas) OW-LU-80 DN80 9~135 (liquid) 90~900 (gas) OWLU-100 DN100 14~200 (gas).

3. What are the measurement ranges of vortex flowmeters?

1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;

2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;

3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15

1.2-6; DN20

1.5---10； DN25：2---16； DN32

1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130； DN100：18---160； ..... Gas measurement: (unit: m3/h): DN15:4--28; DN20：6---40； DN25：8---50； DN32：15---150； DN40：18---180； DN50：25---480； DN65：50---500； DN80：80---800； DN100：120---1200； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangqiang Automation Technology Co., Ltd.... Is it possible to use a DN150 caliber vortex flowmeter for measuring sewage?

The maximum range of the DN150 caliber vortex flowmeter for measuring sewage is 400m3/h, and the minimum range is 40m3/h. The unit here refers to the calculation in cubic meters per hour. The range of the vortex flowmeter for measuring liquids is relatively large, so the DN150 caliber vortex flowmeter can be used to measure sewage as long as the measurement range is between 0-400m3/h.

5. Flow range of steam vortex flowmeter

The flow range o
