Emerson Mag Flow Meter Troubleshooting: Diagnosing Rosemount 8705 Signal Faults
Quick Answer: Rosemount 8705 electromagnetic flow meter signal faults usually come from empty pipe detection, coated electrodes, grounding problems, or a faulty 4-20 mA loop. Check the basics before replacing any part. Silver Automation Instruments can supply a direct replacement mag meter or help you diagnose the transmitter if the cost of an Emerson repair is too high.
Signal Fault Symptoms You Will See On Site
Engineers often see a noisy flow reading, zero flow with a full pipe, or a fixed 4-20 mA output at 3.8 mA or 22 mA. Some plants in Vietnam and Saudi Arabia report that the display shows 0.000 m3/h while the pump is running. Others see flow values jumping plus or minus 20 percent within one second. These readings are not normal for a Rosemount 8705. A healthy unit on a clean water line with a stable pump should hold a steady value within 1 percent of actual flow.
Check Power And Wiring First
Open the transmitter housing and confirm the supply voltage matches the nameplate. Most Rosemount 8705 units accept 90 to 250 V AC or 24 V DC. A loose terminal or a burnt fuse causes intermittent signal loss. Use a multimeter to check the 4-20 mA loop. If the loop reads below 3.5 mA or above 22 mA, the transmitter is in alarm. HART communication may still work but the analog signal will be invalid.
Next, inspect the electrode cable and coil cable. Separate the signal cable from power cables by at least 300 mm. A variable frequency drive near the pipe can induce 50 Hz noise. We have seen this on customer sites many times. Move the cable or add shielded twisted pair cable. Check the cable shield is grounded at one end only.
Empty Pipe And Coated Electrodes
Empty pipe is the most common cause of a 22.8 mA alarm on a Rosemount 8705. If the pipe drains at night or a pump stops, the meter detects air. Set the empty pipe function correctly or disable it if the line always runs full. In a wastewater lift station, the meter may run dry for hours. That creates false low flow or empty pipe alarms.
Coated electrodes cause a gradual loss of signal. Oily sludge in a chemical plant can cover the electrodes with a non-conductive layer. The transmitter then reads lower flow than actual. Clean the electrodes with a soft cloth and warm water. For frequent coating, ask about a replacement mag meter with a PTFE or PFA liner and self-cleaning electrodes. In one case, a paint manufacturer in Southeast Asia replaced a Rosemount 8705 after the third electrode cleaning because the coating returned within two weeks.
Grounding And Process Noise
Poor grounding causes unstable readings. The Rosemount 8705 needs a good ground connection to the process fluid. Use grounding rings or a grounding electrode if the pipe is lined or non-metallic. A plastic pipe without grounding rings will create a floating signal. Install grounding rings at both ends of the meter. The resistance between the ground ring and earth should be below 10 ohms. In practice, most engineers skip this part on PVC lines and then see a noisy signal.
Process noise can also come from air bubbles or solid particles. A slurry line with 10 percent solids will have a noisy output even if the meter is healthy. Increase damping to 5 or 10 seconds. But first fix grounding and cable routing. A chemical plant in Chile reduced signal jumps by 80 percent after adding grounding rings to a Rosemount 8705 on a lined steel pipe.
4-20 mA Loop And HART Diagnostics
Connect a HART communicator to the Rosemount 8705 and check the diagnostic variables. Look at coil resistanc
The 4-20 mA loop may be configured for pulsed output or multi-drop. If the loop is in multi-drop mode, the analog output is fixed at 4 mA and only HART data changes. Check the AO alarm type and loop current mode. A Rosemount 8705 set to high alarm will output 22 mA on a fault. The control system may interpret this as full scale flow. That creates a dangerous situation on a chemical dosing line.
When To Replace The Flow Tube Or Transmitter
A Rosemount 8705 repair can be expensive if the liner is cracked or the coil is damaged. A cracked PTFE liner allows fluid to reach the electrodes and coils. You may see zero flow or a short circuit. If the housing has moisture inside or the coil resistance is open, you need a replacement. A mechanical dent in the flow tube also changes the magnetic field. Do not try to repair the liner in the field. That work must be done by a specialist. Silver Automation Instruments supplies new electromagnetic flow meters in sizes from DN15 to DN2000. We match the process connections, liner material, and signal outputs to your existing Rosemount 8705.
Silver Instruments Replacement Options And Support
Silver Automation Instruments offers electromagnetic flow meters for water, wastewater, chemicals, food and beverage, and marine service. Our meters support 4-20 mA HART, RS485 Modbus, pulse output, and digital displays. We can supply compact or remote versions. For a Rosemount 8705 replacement, send us the pipe size, flow range, pressure, temperature, and conductivity. Common liners include PTFE, PFA, neoprene, and polyurethane. Electrodes are 316L, Hastelloy, titanium, or tantalum. We ship to Southeast Asia, Oceania, Latin America, Africa, and the Middle East. Contact Silver Automation Instruments by phone at +86-25-68650347, WhatsApp at +86-25-52155837, or WeChat at +86 15365082610. Our website is flow-meter.com.au.
FAQ
Why does my Rosemount 8705 show 22.8 mA with a full pipe?
The meter may be in empty pipe alarm, or the analog output is set to high alarm. Check the empty pipe setting with a HART communicator. If the pipe is full but the electrode is coated, the meter may think the pipe is empty. Clean the electrode and check the empty pipe value.
Can I use a Silver Instruments mag meter as a direct replacement for a Rosemount 8705?
Yes. We match line size, flange standard, liner, electrodes, and output signals. Send us the original model code and process data. We will confirm a replacement within 24 hours.
What conductivity level does a Rosemount 8705 need?
The process liquid should be at least 5 µS/cm for a standard electromagnetic flow meter. Some units work down to 2 µS/cm with special electrodes. Pure water below 1 µS/cm may not be reliable. Use a clamp-on ultrasonic meter for very low conductivity fluids.
Why does the flow signal jump when the pump starts?
This is usually caused by air bubbles, a partially full pipe, or electrical noise from a VFD. Install a flow straightener if possible, increase damping, and separate signal cables from motor cables.
How do I test the Rosemount 8705 electrodes?
Use a HART communicator to check electrode resistance. A normal value is usually below 50 k Ohm. A high value means a coated electrode or an open connection. You can also do a visual check if the meter is removed from the line.
