1. Characteristics of Aniuba flowmeter

Aniuba flowmeter is a device based on the pitot tube measurement principle, which measures the flow rate by measuring the pressure difference upstream and downstream of the blocking body. Its core features are as follows: it has a wide measurement range and is suitable for industrial scenarios with pipeline diameters ranging from DN20 to DN12000. It can accurately measure various energy media such as liquids, fuel gases, steam, and gases, covering the needs of small and large industrial pipelines. The straight pipe section requires low installation, and the length of the front and rear straight pipe sections is only one-third of that of standard orifice plates and other throttling devices. For example, a standard orifice plate requires a straight pipe section with a diameter of 10 times, while Anuba only requires 3-4 times, significantly reducing the cost of pipeline renovation, especially suitable for sites with limited space or complex pipeline layouts. Supports non-stop disassembly and installation with pressure operation, and maintenance or replacement can be completed without interrupting the process flow. This feature avoids production losses caused by the need to shut down during the maintenance of flow meters, and is particularly suitable for critical links in continuous production, such as the chemical and power industries. Easy and efficient installation process only requires three steps: making holes in the pipeline and welding the joint body; Insert the flowmeter body; Tighten the pressure cap for fixation. The entire process does not require tedious calibration or large equipment, and can be completed by a single person, reducing installation time by more tha

n 50% compared to traditional equipment. The energy-saving effect is significant, and the pressure loss is only less than 5% of the standard orifice plate. Taking the DN200 pipeline as an example, if the fluid pressure is 1MPa, the pressure loss when using orifice plate Youhui is about 0.02MPa, while Anuba is only 0.001MPa, saving tens of thousands of yuan in annual power costs. Long term operation can significantly reduce energy consumption and meet the requirements of green production. Durability and reliability, wear resistance: The blocking body is made of special alloy material with surface hardening treatment, which can maintain long-term accuracy even when measuring media containing particles (such as sewage and steam), and its lifespan is 3-5 times that of conventional orifice plates. Leak free design: The integrated structure eliminates the risk of leakage that may arise from conventional flange connections, especially suitable for high-pressure or toxic medium scenarios. High strength: able to withstand harsh working conditions such as pipeline vibration and sudden temperature changes, with better stability than flow meters such as turbines and vortex streets. The comprehensive cost (purchase+installation+maintenance) of economic advantages is reduced by about 30% compared to standard orifice plates. Reducing straight pipe sections saves pipeline material costs; Operating under pressure to avoid production downtime and losses; Low voltage loss reduces power consumption and has significant cost advantages throughout the entire lifecycle. In addition to conventional media, it can also measure high temperature (≤ 550 ℃), high pressure (≤ 42MPa) media, and low flow velocity (≥ 0.3m/s) fluids, filling the applicatio
