What are the measurement ranges of vortex flowmeters?

1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;

2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;

3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15

1.2-6; DN20

1.5---10； DN25：2---16； DN32

1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130； DN100：18---160； ..... Gas measurement: (unit: m3/h): DN15:4--28; DN20：6---40； DN25：8---50； DN32：15---150； DN40：18---180； DN50：25---480； DN65：50---500； DN80：80---800； DN100：120---1200； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangqiang Automation Technology Co., Ltd.... Www.qszdh. com

2. What are the differences between vortex street and turbine flowmeter?

The difference between a vortex flowmeter and a turbine flowmeter mainly lies in their working principle, applicable medium, cost, and application scenarios, as follows:

1. Differences in working principle. Vortex flowmeter: When fluid flows through non streamlined obstacles, periodic vortices (vortex streets) will form behind the obstacles.

. The vortex frequency is directly proportional to the fluid velocity, and the flow rate can be calcu

2. Differential vortex flow meters suitable for resolving quality issues: liquids such as water, oil, alcohol, chemical raw materials, etc. Gases: air, oxygen, nitrogen, natural gas, coal gas, etc. Steam: saturated steam, superheated steam. Characteristics: Strong adaptability to fluid types, capable of covering multiple media. Turbine flowmeter: gases: air, nitrogen, oxygen, hydrogen, biogas, natural gas, etc. Steam: Suitable for steam flow measurement. Liquids: Clean, low viscosity liquids (such as those in the petroleum, food and beverage, and pharmaceutical industries). Characteristics: High requirements for fluid cleanliness, high viscosity may affect measurement accuracy.

III. Differences in Cost and Application Scenarios of Hebe family Vortex flowmeter: Cost: slightly higher than turbine flowmeter.
