1. The enrichment flow rate of the Ali Carter flowmeter does not display

2. What are the common usage faults of electromagnetic flowmeters?

3. What is a mass flow meter

4. If there is a problem with the mass flow meter and the flow rate is not controlled, seek help

5. How to calculate the water output of the flow meter

The calculation of the water output of the flow meter requires selecting the corresponding formula according to the type, and the core is to obtain the volumetric flow rate by combining the flow rate, measurement times, or mass flow rate with density conversion.. After understanding the differences in flowmeter types, the specific calculation methods can be classified into three typical modes.

1. Velocity flowmeter: The product formula of flow velocity and area is $Q=A × v $, where the cross-sectional area of the pipeline $A $needs to be calculated based on the inner diameter. For example, for a pipeline with an inner diameter of 0.2 meters and an area of $A=\ pi × (0.1) ^ 2 ≈ 0.0314 $square meters, if the measured flow rate $v=2 $meters/second, the instantaneous flow rate $Q=0.0628 $cubic meters/second. To convert

The mass flow meter has entered the water

the flow rate per hour, it needs to be multiplied by 3600 seconds, resulting in 226.08 cubic meters/hour.

2. Volumetric flowmeter: The formula for multiplying the fixed volume by the number of measurements is $Q=n × V $, and the key is the measurement chamber volume $V $and the number of full discharges per unit time $n $. For example, for a certain flowmeter, if the measurement chamber $V=0.001 $cubic meters and the number of measurements $n=5000 $per hour, the total flow rate $Q=5 $cubic meters. Reflecting cumulative quantity

3. Mass flowmeter: The formula for the ratio of mass flow rate to density is $Q-v=Q_m/{\ rho} $, and the fluid density $\ rho $needs to be known. If the measured mass flow rate $Q_m=100 $kg/s and fluid density $\ rho=1000 $kg/cubic meter, then the volume flow rate $Q-v=0.1 $cubic meter/s is suitable for scenarios that require high quality accuracy. In summary, when selecting a method, it is necessary to clarify the type of flowmeter, obtain corresponding parameters (such as flow rate, count or mass flow rate), and input the values into the formula to complete the water quantity calculation.
