1. How to determine the direction of the flowmeter?
The direction of the flowmeter needs to be determined based on the type through identification arrows, internal structure, or instructions. The core methods are as follows:
1. The determination of the fluid direction of the sail, equipment, water meter mainly relies on two points: 1 Dial Arrow: The dial is cast with arrow markings, and the direction of the arrow indicates the direction of water flow. two Import and export labeling: The table body is usually labeled with "inlet" and "outlet", with water flowing from the inlet to the outlet. The direction of water flow impact on the internal impeller is consistent with the arrow.
Secondly, the flow arrow stopper on the electromagnetic flowmeter housing or sticker is the core judgment basis.
. During installation, it is necessary to ensure that the fluid direction inside the pipeline is consistent with the arrow. If the standard balance is unclear, refer to the installation diagram in the equipment manual to avoid measurement errors caused by reverse connection.III. The smoothness of turbine rotation in a turbine flowmeter depends on the flow direction: 1 Shell arrow: The flow arrow marked on the body directly corresponds to the direction of fluid entry. two Turbine rotation direction: The water flow needs to impact from the front of the turbine blades to ensure forward rotation of the turbine. Reverse installation can easily lead to abnormal counting or mechanical wear.
4. The installation direction of the ultrasonic flowmeter sensor determines fluid recognition: 1 Instructions: The upstream sensor (transmitter) and downstream sensor (receiver) need to be fixed at the specified di
2. What is a flow reversal meter?
Currently, the flow reversal meter is not defined by standard terminology, but according to actual scenarios, it can be understood as a flow meter with bidirectional flow measurement function or related solutions for flow direction reversal problems.
. 1. Regarding the solution to the problem of reverse flow direction, if the flowmeter displays reverse flow due to installation or malfunction, it usually needs to be investigated from both hardware and software levels: • Hardware level: Check whether the sensor is aligned with the actual flow direction of the fluid, and whether the pipeline is abnormal in flow direction due to impurity accumulation or mechanical damage. • Software level: Switch flow direction parameters through the device settings interface, or recalibrate the device range. Intelligent flow meters can be equipped with software for remote correction of data logic. 2. Flow meters with bidirectional measurement function. Some high-precision flow meters support forward and reverse flow monitoring, such as Coriolis mass flow meters: By detecting changes in fluid inertia force, they can automatically identify the direction of bidirectional flow. Ultrasonic
