Krone Flow Meter: Sourcing Industrial Magnetic and Coriolis Mass Sensors
Quick Answer
Need Krone magnetic flow meters or Coriolis mass sensors for your process line? Silver Instruments supplies these devices with full technical selection support. Give us your fluid type, pipe size (DN15 to DN2000), temperature, and pressure, and we will return a matching Krone model number with a price quote within 24 hours.
What Makes Krone Sensors a Practical Choice
Engineers in water treatment, food processing, and chemical dosing plants often choose Krone electromagnetic flow meters because they handle conductive liquids without moving parts. A flowmeter with a PTFE liner and Hastelloy electrodes works reliably in corrosive acids like hydrochloric acid at concentrations up to 30 percent. The magmeter outputs 4-20 mA HART, pulse, or RS485, so it drops right into existing PLC systems.
Krone Coriolis mass flow sensors measure mass flow, density, and temperature directly. This means you do not need separate density meters. A sugar refinery in Thailand we worked with replaced their old batching system with a Krone Coriolis meter. They now measure syrup mass flow from 50 kg/h up to 5000 kg/h with 0.1 percent accuracy. The meter also detects air pockets, which prevented a batch error last quarter.
Avoiding Sourcing Mistakes We See in the Field
Here is the thing: many procurement teams send us a datasheet that lists only pipe size and fluid. But a Krone magmeter needs conductivity data. If your water has less than 5 µS/cm, a standard magmeter will not work. We often ask, “Are you measuring demineralized water or condensate?” These fluids require a special design. For Coriolis meters, customers sometimes forget to state the viscosity. A glucose syrup at 80 degrees Celsius and 2000 cP behaves differently in the sensor tube. We have seen a paint manufacturer in Southeast Asia order the wrong sensor because they assumed the fluid behaved like water. The meter gave unstable readings. After we helped them switch to a Krone model with the correct tube geometry, the problem disappeared.
Krone Magnetic Flow Meter Selection by Application
Here are real examples. For a desalination plant seawater intake, we supplied a Krone MFT 2100 magmeter with a rubber liner and titanium electrodes, size DN400. The flow range was 0 to 3500 m3/h. The meter included a remote transmitter with IP68 rating for occasional flooding. For a brewery in Mexico, we sent a Krone MFT 4300 with PFA liner and stainless steel electrodes, DN50. It measured wort flow before fermentation. Accuracy was 0.3 percent, and food grade approval was a hard requirement. A wastewater plant in Vietnam
When to Choose Coriolis Over Magnetic
Magnetic meters require conductive liquid. If you dose additives, like methanol or oil, the liquid is non conductive. Coriolis mass meters then become the only inline option. A biodiesel plant in Malaysia asked us for a Krone Coriolis meter to measure methanol injection rate. The flow range was 15 to 200 kg/h. They needed ATEX Zone 1 certification, so we provided a Krone CMS-100 with Ex d approval. The 4-20 mA output connected to their safety system.
Quick Specs and What to Send for a Quote
To get a Krone flow meter price from Silver Instruments, please email [email protected] with this data. For magnetic flow meter: pipe size (DN), liner material, electrode material, fluid name, conductivity, temperature, pressure, max and min flow rate. For Coriolis mass sensor: flow range in kg/h, process temperature, density range, viscosity, connection size, hazardous area classification. You can also reach us by phone at +86-25-68650347, WhatsApp +86-25-52155837, or WeChat +86 15365082610. We answer quote requests in English and Spanish.
FAQ
Can Silver Instruments supply Krone sensors for small pipe sizes like DN10? Yes, we provide Krone magmeters from DN10 and Coriolis sensors from DN06. Mention your connection standard when you inquire.
Do you keep stock in Australia or Asia? We hold common Krone models in our Nanjing warehouse and ship to Sydney, Melbourne, Bangkok, Jakarta within 5-7 days by air. Express shipping for urgent needs is available.
Are Krone flow meters suitable for custody transfer? Some Krone Coriolis meters have OIML R117 certification. Let us know your local metrology requirements and we will check the certificate against your country regulations.
How do I know which liner to choose for my chemical? Send us the chemical name, concentration, and temperature. We match it with Krone chemical resistance charts. For complex mixtures, we can arrange a sample test with the manufacturer.
What is the typical lead time for a customized Krone Coriolis meter? For standard models, 2-3 weeks. For exotic materials like Tantalum or high pressure above 100 bar, expect 6-8 weeks. We inform you of any delays before you place the order.
Send your inquiry to [email protected] or call +86-25-68650347. You can message us on WhatsApp +86-25-52155837 or WeChat +86 15365082610. Silver Automation Instruments supports your Krone flow meter project from selection to delivery.
